Post From: ACSIL REPLAY PROBLEM

[2015-08-26 19:05:27]
User668659 - Posts: 6
Hello! I've recently notice that a study i made with some moving averages signals doesn't work well in realtime/replay(Accurate trading system back test mode). If i disconnect the live data and apply the study it works without a problem. The study draw some lines above/under price based on two movavg positions and draw a triangle above/under the crossing point of another two movavg.
After a replay or working in real time appear signals that doesn't exist.
Maybe there is something i don't know that changes in ACSIL under a replay/real time.
I left the screenshots before/after replay.
Here is the code:


#include "sierrachart.h"
#include "scstudyfunctions.h"
#define RED RGB(255,0,0)
#define BLUE RGB(0,128,255)

SCDLLName("MovSlope")

SCSFExport scsf_MovSlope(SCStudyInterfaceRef sc){

  SCSubgraphRef MovSlope1 = sc.Subgraph[0];
  SCSubgraphRef MovSlope2 = sc.Subgraph[1];
  SCSubgraphRef MovSlope3 = sc.Subgraph[2];
  SCSubgraphRef MovSlope4 = sc.Subgraph[3];
  SCSubgraphRef MovSlope5 = sc.Subgraph[4];
  SCSubgraphRef MovSlope6 = sc.Subgraph[5];
  SCSubgraphRef MovSlope7 = sc.Subgraph[6];
  SCSubgraphRef MovSlope8 = sc.Subgraph[7];

  if (sc.SetDefaults){
    sc.GraphName = "MovSlope";
    sc.StudyDescription = "MovSlope";

    sc.AutoLoop = 1;
    sc.FreeDLL = 0;
    sc.GraphRegion = 0;

    MovSlope1.Name = "MV1";
    MovSlope1.DrawStyle = DRAWSTYLE_HIDDEN;
    MovSlope1.LineStyle = LINESTYLE_SOLID;
    MovSlope1.LineWidth = 3;
    MovSlope1.DrawZeros = false;

    MovSlope2.Name = "MV2";
    MovSlope2.DrawStyle = DRAWSTYLE_HIDDEN;
    MovSlope2.LineStyle = LINESTYLE_SOLID;
    MovSlope2.LineWidth = 3;
    MovSlope2.DrawZeros = false;

    MovSlope3.Name = "MV3";
    MovSlope3.DrawStyle = DRAWSTYLE_LINE_SKIPZEROS;
    MovSlope3.LineStyle = LINESTYLE_SOLID;
    MovSlope3.LineWidth = 3;
    MovSlope3.DrawZeros = false;

    MovSlope4.Name = "MV4";
    MovSlope4.DrawStyle = DRAWSTYLE_LINE_SKIPZEROS;
    MovSlope4.LineStyle = LINESTYLE_SOLID;
    MovSlope4.LineWidth = 3;
    MovSlope4.DrawZeros = false;

    MovSlope5.Name = "MV5";
    MovSlope5.DrawStyle = DRAWSTYLE_TRIANGLEDOWN;
    MovSlope5.LineWidth = 3;
    MovSlope5.DrawZeros = false;

    MovSlope6.Name = "MV6";
    MovSlope6.DrawStyle = DRAWSTYLE_TRIANGLEUP;
MovSlope6.LineWidth = 3;
    MovSlope6.DrawZeros = false;

    MovSlope7.Name = "MV7";
    MovSlope7.DrawStyle = DRAWSTYLE_HIDDEN;
    MovSlope7.LineStyle = LINESTYLE_SOLID;
    MovSlope7.LineWidth = 3;
    MovSlope7.DrawZeros = false;

    MovSlope8.Name = "MV8";
    MovSlope8.DrawStyle = DRAWSTYLE_HIDDEN;
    MovSlope8.LineStyle = LINESTYLE_SOLID;
    MovSlope8.LineWidth = 3;
    MovSlope8.DrawZeros = false;

    sc.Input[1].Name = "Red";
    sc.Input[1].SetColor(RED);

    sc.Input[2].Name = "Blue";
    sc.Input[2].SetColor(BLUE);

    return;
  }

  SCFloatArrayRef Last = sc.Close;

  sc.SimpleMovAvg(Last, MovSlope1, sc.Index, 5);

  sc.SimpleMovAvg(Last, MovSlope2, sc.Index, 10);

  sc.SimpleMovAvg(Last, MovSlope7, sc.Index, 12);

  sc.SimpleMovAvg(Last, MovSlope8, sc.Index, 16);

  float mov1 = MovSlope1[sc.Index];
  float mov2 = MovSlope2[sc.Index];
  float mov7 = MovSlope7[sc.Index];
  float mov8 = MovSlope8[sc.Index];

  if (mov1 > mov2)
  {
    MovSlope3[sc.Index] = mov1 + 6.0f;
    MovSlope3.DataColor[sc.Index] = sc.Input[2].GetColor();
  }
  else if (mov1 < mov2)
  {
    MovSlope4[sc.Index] = mov1 - 6.0f;
    MovSlope4.DataColor[sc.Index] = sc.Input[1].GetColor();
  }


  if ((MovSlope7[sc.Index - 1] > MovSlope8[sc.Index - 1]) && (MovSlope7[sc.Index] < MovSlope8[sc.Index])){
    MovSlope5[sc.Index] = mov1 + 8.5f;
    MovSlope5.DataColor[sc.Index] = sc.Input[1].GetColor();
  }
  else if ((MovSlope7[sc.Index - 1] < MovSlope8[sc.Index - 1]) && (MovSlope7[sc.Index] > MovSlope8[sc.Index])){
    MovSlope6[sc.Index] = mov1 - 8.5f;
MovSlope6.DataColor[sc.Index] = sc.Input[2].GetColor();
  }
}

image1.png / V - Attached On 2015-08-26 19:01:02 UTC - Size: 28.41 KB - 324 views
image2.png / V - Attached On 2015-08-26 19:01:12 UTC - Size: 29.03 KB - 317 views
